k8s-api-access-control

1. 访问控制流程

access-control

访问控制流程整体分三步走：身份认证–>鉴权–>准入控制

2. 身份认证

普通身份：由集群的证书机构签名的合法证书的用户（下面介绍两种通过证书签发获取的方式）
管理身份：服务账号与一组以 Secret 保存的凭据相关（sa）
匿名身份：匿名访问默认情况下是被禁用的，可以通过–anonymous-auth=true来启用

2.1 私钥审批认证获取证书

key:通常指私钥 csr:证书签名申请，这不是证书 crt:证书

通过openssl创建私钥

openssl genrsa -out user01.key 2048
openssl req -new -key user01.key -out user01.csr -subj "/CN=user01"

通过创建CertificateSigningRequest将私钥提交到集群这里的request是证书的base64加密通过cat user01.csr | base64 | tr -d "\n"获得

cat <<EOF | kubectl apply -f -
apiVersion: certificates.k8s.io/v1
kind: CertificateSigningRequest
metadata:
  name: user01
spec:
  request: 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
  signerName: kubernetes.io/kube-apiserver-client
  expirationSeconds: 864000  # ten day
  usages:
  - client auth
EOF

# 查看集群的证书，这个时候的证书是Pending状态
kubectl  get csr
# 批准证书，批准以后证书变为Approved,Issued
kubectl certificate approve user01
# 获取证书，到这里我们就完成了身份的认证得到身份user01
kubectl get csr user01 -o jsonpath='{.status.certificate}'| base64 -d > user01.crt

2.2 通过集群证书签发私钥得到证书

整体流程是相似的只是在签发的时候有一点不一样

这里的/home/lee/kind/pki需要根据自己的具体目录指定

# 创建私钥
openssl genrsa -out user02.key 2048
# 生成csr文件
openssl req -new -key user02.key -out user02.csr -subj "/CN=user02/"

# 使用创建集群的ca文件给csr签发证书文件得到crt文件
# 这里的/home/lee/k8s/kind/pki需要指定为自己的目录
openssl x509 -req -in user02.csr -CA /home/lee/k8s/kind/pki/ca.crt -CAkey /home/lee/k8s/kind/pki/ca.key -CAcreateserial -out user02.crt -days 365
# 这样就得到了用户user02

3. rbac (Role-Based Access Control)

使用上面创建的证书来访问集群资源

# 创建角色，制定可以访问的资源和可以执行的操作
kubectl create role role01 --verb=create --verb=get --verb=list --verb=update --verb=delete --resource=pods
# 绑定角色和权限
kubectl create rolebinding role01-binding-user01 --role=role01 --user=user01
# 设置客户端证书
kubectl config set-credentials user01 --client-key=k8s.key --client-certificate=user01.crt --embed-certs=true
#设置上下文（注意这里的--cluster 需要查看自己的集群是啥名字）
# 可以通过`kubectl config view`查看自己的集群名字
kubectl config set-context user01 --cluster=mycluster --user=user01
kubectl config use-context user01

4. Node

Node鉴权是k8s apiserver的一种特殊用途的鉴权模式，专门用于对kubelet发出的请求进行鉴权
Node鉴权组件默认允许kubelet执行一系列操作
- 如对services, endpoints, nodes, pods, secrets, configmaps, pvcs以及绑定到kubelet所在节点的与Pod相关的持久化卷的读取操作,写入节点和节点状态，Pod和Pod状态，事件信息的写入操作

准入插件NodeRestriction用来限制kubelet只能修改写入其自己所在节点相关的资源

5. ABAC (Attribute-based access control)

ABAC 通过使用将属性组合在一起的策略来向用户授予访问权限
要启用 ABAC 模式，可以在启动时指定 –authorization-policy-file=SOME_FILENAME 和 –authorization-mode=ABAC。

策略访问文件格式如下：

{"apiVersion": "abac.authorization.kubernetes.io/v1beta1", "kind": "Policy", "spec": {"group":"system:authenticated",  "nonResourcePath": "*", "readonly": true}}
{"apiVersion": "abac.authorization.kubernetes.io/v1beta1", "kind": "Policy", "spec": {"group":"system:unauthenticated", "nonResourcePath": "*", "readonly": true}}
{"apiVersion": "abac.authorization.kubernetes.io/v1beta1", "kind": "Policy", "spec": {"user":"admin",     "namespace": "*",              "resource": "*",         "apiGroup": "*"                   }}
{"apiVersion": "abac.authorization.kubernetes.io/v1beta1", "kind": "Policy", "spec": {"user":"scheduler", "namespace": "*",              "resource": "pods",                       "readonly": true }}
{"apiVersion": "abac.authorization.kubernetes.io/v1beta1", "kind": "Policy", "spec": {"user":"scheduler", "namespace": "*",              "resource": "bindings"                                     }}
{"apiVersion": "abac.authorization.kubernetes.io/v1beta1", "kind": "Policy", "spec": {"user":"kubelet",   "namespace": "*",              "resource": "pods",                       "readonly": true }}
{"apiVersion": "abac.authorization.kubernetes.io/v1beta1", "kind": "Policy", "spec": {"user":"kubelet",   "namespace": "*",              "resource": "services",                   "readonly": true }}
{"apiVersion": "abac.authorization.kubernetes.io/v1beta1", "kind": "Policy", "spec": {"user":"kubelet",   "namespace": "*",              "resource": "endpoints",                  "readonly": true }}
{"apiVersion": "abac.authorization.kubernetes.io/v1beta1", "kind": "Policy", "spec": {"user":"kubelet",   "namespace": "*",              "resource": "events"                                       }}
{"apiVersion": "abac.authorization.kubernetes.io/v1beta1", "kind": "Policy", "spec": {"user":"alice",     "namespace": "projectCaribou", "resource": "*",         "apiGroup": "*"                   }}
{"apiVersion": "abac.authorization.kubernetes.io/v1beta1", "kind": "Policy", "spec": {"user":"bob",       "namespace": "projectCaribou", "resource": "*",         "apiGroup": "*", "readonly": true }}

例如，如果你要使用 ABAC 将（kube-system 命名空间中）的默认服务账号完整权限授予 API，则可以将此行添加到策略文件中：

{"apiVersion":"abac.authorization.kubernetes.io/v1beta1","kind":"Policy","spec":{"user":"system:serviceaccount:kube-system:default","namespace":"*","resource":"*","apiGroup":"*"}

6. 准入控制器

启用准入控制器kube-apiserver --enable-admission-plugins=NamespaceLifecycle,LimitRanger ...
关闭准入控制器kube-apiserver --disable-admission-plugins=PodNodeSelector,AlwaysDeny ...
要查看哪些插件是被启用kube-apiserver -h | grep enable-admission-plugins
每个准入控制器的作用,参考。
准入控制过程分为两个阶段。第一阶段，运行变更准入控制器。第二阶段，运行验证准入控制器。某些控制器既是变更准入控制器又是验证准入控制器

如果两个阶段之一的任何一个控制器拒绝了某请求，则整个请求将立即被拒绝，并向最终用户返回错误

7. 动态准入控制

Mutating可以修改请求的yaml（会优先调用）
Validating只能验证请求的yaml
具体参考官方文档

7.1 MutatingAdmissionWebhook

apiVersion: admissionregistration.k8s.io/v1
kind: MutatingWebhookConfiguration
webhooks:
  - name: my-webhook.example.com
    namespaceSelector:
      matchExpressions:
        - key: runlevel
          operator: NotIn
          values: ["0", "1"]
    rules:
      - operations: ["CREATE"]
        apiGroups: ["*"]
        apiVersions: ["*"]
        resources: ["*"]
        scope: "Namespaced"

7.2 ValidatingAdmissionWebhook

apiVersion: admissionregistration.k8s.io/v1
kind: ValidatingWebhookConfiguration
webhooks:
  - name: my-webhook.example.com
    namespaceSelector:
      matchExpressions:
        - key: environment
          operator: In
          values: ["prod", "staging"]
    rules:
      - operations: ["CREATE"]
        apiGroups: ["*"]
        apiVersions: ["*"]
        resources: ["*"]
        scope: "Namespaced"
